Miller XMT 350 CC/CV 6-Pack Rack, Tweco®, fused for 460/575V #907406

Multi-Voltage
3 Phase
Multi-Process
3-Year Warranty

Miller XMT 350 CC/CV 6-Pack Rack / Tweco #907406

Designed for use with Miller’s SuitCase feeders, this durable 6-Pack Rack is a great way to consolidate your welding machines at construction sites and other locations with multiple welders. This rack has fused 460/575 V and provides for CC/CV welding processes (Stick, TIG, MIG and FCAW, as well as air carbon arc cutting and gouging). One easy-to-use Tweco style connection lets you connect up to six inverters with one primary power drop. Input power of 208-575 VAC at 50/60 Hz. Measures 43” L x 34.375” W x 59.375” H.

Features:

One easy connection allows six welders to be connected with one primary power drop.

Meets IP23, which is more stringent than IP23S or IP23M ratings, providing the most reliable outdoor package.

Protected from the Elements

The electrical junction box is located well under the galvanized roof panel. Rack roof panel and power source shelves are fabricated from galvanized steel and painted for added protection in harsh environments.

Protected Electrical Connections

Liquid-tight strain reliefs provided on both welding power source and electrical junction box. Strain relief is designed to resist saltwater, alcohol, oil, grease, and common solvents.

Lifting eyes simplify transportation using a crane or overhead lifting device. Lift truck side and end fork pockets in the base to enable loading and worksite repositioning with a forklift.

Isolated work terminal provides a convenient connection point for common workpiece construction.

These racks can be equipped with optional running gear. The large five-inch diameter wheels enable the rack to be moved over grating and driveway gravel.
